DJI Mavic 3 Gimbal Calibration

Written By: Arty

Comments: 5

Difficulty

Easy

Steps

Time Required

25 - 30 minutes

Introduction

Hi everyone. In this video tutorial, I'll show you how to calibrate the gimbal camera on a DJI Mavic 3 drone.

After replacing the motherboard or gimbal camera, you need to calibrate the drone. How to calibrate the DJI Mavic 3, watch this manual.

Step 1

Download Programs for Calibration Gimbal Python: https://www.python.org/
PySerial: https://pypi.org/project/pyserial/#files
GitHub: https://github.com/o-gs/dji-firmware-too...
7-zip: https://7-zip.org/

Step 2

First script to run calibration
py comm_og_service_tool.py --port com pcode GimbalCalib JointCoarse

Step 3

Second gimbal calibration script
py comm_og_service_tool.py --port com pcode GimbalCalib LinearHall

Conclusion

To reassemble your device, follow these instructions in reverse order.

Author

Arty

Member since: 27/10/19

13514 Reputation

5 comments

pour le mavic 3 wm260 impossible de trouvez le --port com ne marche pas.

gregory noel -

If your PC does not detect your drone in the device manager, most likely your PC did not find drivers for your drone, download and install DJI Assistant for your drone model.

Arty -

Will this work on the Mavic 3?

Daniel Carpenter -

Good Video but on Mavic 3 port com doesn't displayed even when DJI Assistant 2 for Mavic 3 is installed

Bashir Kapitene -

Waiting for software update

Arty -
